Brand Name	Ximax
Colour	White
Material	Steel
Manufacturer Model No	7887H
Wear Type	N/A
Certifications Met	EN 442
Country of Origin	N/A
BTU	2952 BTU
Connection Size	1/2 "
Construction Material (Plumbing)	Steel
Delta T	Delta T50°C
Finish Code	Finished to RAL 9016
Max. Working Pressure	4 bar
Max. Working Temperature	120 °C
Model Name	Fortuna
Mounting Orientation	Vertically-Mounted
No. Of Sections	7
No. of Radiator Profiles	Single
Orientation	Vertical
Power Output (Watts/Kw)	865 W
Product Height	1800 mm
Product Width	410 mm
Projection from Wall (Std Bracket)	87 mm
Radiator Accessories Included	Wall Fixings, Plug & Vent Included
Radiator Coating & Finish	Powder-Coated
Radiator Colour	White
Radiator Height Band	1800mm or Greater
Radiator Product Type	Designer
Radiator Water Content	10.6 Ltr
Radiator Width Band	301-500mm
Shape Orientation	Radiator is taller than it is wide
Suitable System	Suitable for Hot Water Central Heating Systems
Test Pressure	15 bar
Total Product Weight	22 kg
Wall to Centre (Standard Bracket)	48 mm

Fortuna vertical radiators are a range of contemporary, tubular upright radiators with a high heat output and are suitable for use with existing hot water central heating systems. Combining a sturdy steel construction with a high quality, powder-coated finish, these tall radiators provide a stylish addition to your room.

Brand Name	Ximax
Colour	White
Material	Stainless steel
BTU	1562BTU
Heat output	458W
Maximum operating temperature	120°C
Model name/number	FOR180236W
Outlet position	Side
Product depth	55mm
Product height	1800mm
Product weight	13.5kg
Product width	236mm
Radiator type	Designer
Standard	BS EN 442
Wall to centre (with standard bracket)	48mm
Orientation	Vertical
Product code	9006547445909

Brand Name	Ximax
Colour	White
Material	Steel
Manufacturer Model No	TFD1800410W
Certifications Met	Manufactured and tested to EN-442
Connection size	1/2"
Heat output calculated at	Delta T50°C
Max working temperature	120°C
Projection from wall	102 mm
Wall to centre	62 mm
Pressure tested to	13 bar
Max working pressure	10 bar
Warranty	10 years
Range Name	Bristol
Depth (mm)	92mm
Width (mm)	410mm
Pack contents	Radiator, fixings, blank and air plug
Inlet Connection	1/2"
Finish	Gloss
Min. pressure (bar)	0.5 bar
Pipe Centres	410mm
BTU	4147
Max. pressure (bar)	10
Coating	Powder Coated
Radiator Style	Oval
BTU range	4001-6000
Fitted Depth	102mm
Radiator Profile	Double Panel
Number of Sections	7
Delta T	Delta T50°C
Radiator Orientation	Vertical
Weight (Kg)	33.77KG
